ST3118GS-D
18 Port Gigabit Ethernet Switch
- 16 10/100/1000M RJ45 ports and 2 gigabit SFP ports
- MAC address auto-learning & auto-aging
- 4KV surge protection
- Supports 2K MAC addresses
- 36 Gbps backplane bandwidth
- Port isolation, data transmission will not affect the other ports
- Installation is not limited, more convenient networking
- Plug and play, no configuration required
Specification
Hardware
|
Interface |
16 * 10/100/1000M RJ45 port 2 * gigabit SFP |
|
LED |
PWR 1X-18X |
|
Power Supply |
Built-in supply the 12V/1A power |
|
Dimensions (L x W x H ) |
490 * 365 * 280mm |
Switching Features
|
Standard |
IEEE802.3,IEEE802.3u,IEEE802.3z ,IEEE802.3x |
|
Backplane bandwidth |
36G |
|
Packet forwarding rate |
26.78Mbps |
|
Data Transmission Rate |
10Mbps(Half-duplex and Full-duplex) 100Mbps(Half-duplex and Full-duplex) 1000Mbps(Full-duplex) |
|
Model |
Normal mode (default) Port VLAN |
Others
|
Environment |
Operating Temperature: 0℃~40℃ Storage Temperature: -20℃~70℃ Operating Humidity: 10%~90% RH non-condensing Storage Humidity: 5%~90% RH non-condensing |
